- Commodity name: Large scale silicon steel core winding machine
This equipment is used for iron core winding and firing process, and can wind large circular iron cores. It has strong universality and simple operation.
This equipment is used for iron core winding and firing process, and can wind large circular iron cores. It has strong universality and simple operation.
(1) Humanized design of equipment, with safety protection and warning signs for each institution:
(2) Easy to operate when changing models, adjustable with gear edge knob:
(3) Strong compatibility, compatible with both sizes and specifications of circular iron cores:
-
Large scale silicon steel rolling machine
Model HBT-1000
Maximum outer diameter of iron core Φ1000mm
Inner shaft diameter Φ160-Φ800mm Steel sheet width 20 -100mm Thickness of steel sheet 0.18-0.35mm Maximum material outer diameter of the feeding rack 1200mm Expansion range of inner diameter 450-530mm (customizable) Product height 20-100mm Accuracy of both sides of the iron core <0.3mm
Belt winding and conveying speed 10mm/s -300nm/s (depending on the size of the inner and outer diameters of the product)
Equipment failure rate ≤56 (Malfunctions caused solely by equipment)
Equipment and Electrical Appliances 3220VAC: 50/60Hz. Total power: (approximately) 12KT
Compressed air Pressure: 0.4~0.6lP (4kgr 6kgf/square centimeter):
